Features
3mm inner shaft, 1.5mm outer titanium alloy shaft
Japanese NSK φ8*φ3*4 bearings
N52H curved magnets
Motor wires protected
Dynamically balanced
Specifications
KV: 1900KV / 2550KV
Weight(included wire): 21g
Dimension: φ26.8*19mm
Interphase Resistance: 125.3mΩ / 130.8mΩ
Input Volts: 24V / 16V
Peak Current: 19.37A / 24.41A
Max Watt: 464.9W / 390.6W
Mounting Holes: 12*12 φ2mm
Rotor Specifications: Unibell
Shaft Diameter: 1.5mm
Shaft Protruding Length: 5mm
Magnet: N52H Curved
Configuration: 12N14P
Bearing Type: NSK
Bearing Specification: φ8*φ3*4
Winding: Single Strand copper winding
Packing List
1x XING 2005 Motor
4x M2*6 screws
