Features
High-strength 5mm Steel shaft
N52SH High-temperature magnets, NSK bearings
16x16mm hole pattern
Single strand copper winding
6061 CNC machined aluminum top and base parts
Hex bolt shaft set screw
Specifications
Model: XING-E Pro 2306 Motor
KV: 1750KV / 2450KV
Weight(included wire): 33.8g / 33.6g
Dimension: φ29.5*32.2mm
Interphase Resistance: 85.63mΩ / 55.6mΩ
Input Volts: 25.2V / 16.8V
Peak Current: 36.66A / 43.38A
Max Watt: 920.2W / 712.7W
Mounting Holes: 16*16 φ3mm
Rotor Specifications: Unibell
Shaft Diameter: 5mm
Shaft Protruding Length: 13.5mm
Lead: 160mm/20AWG
Magnet: N52H Curved
Configuration: 12N14P
Bearing Type: NSK
Bearing Specification: φ9*φ4*4
Winding: Single Strand copper winding
Packing List
1 x XING-E Pro 2306 motor
4 x M3*8 Screws
1 x M5 Flanged Nylon Insert Lock Nut
